Product Introduction

Feature

  • Applying PLC control system，with high efficiency and easy to operate
  • Human-machine interface can monitor working state and fault diagnosis
  • 6 axis servo motors and 3 axis linkage ensure precise position
  • Wetted parts are all made of No-rust material
  • Excellent off line Low-E glass processing
  • Automatic identification of glass size function

Technical Data

  • Max glass size：2500×3000mm
  • Min glass size：300×700mm
  • Glass thickness：3-10mm
  • Working speed：0-20m/min
  • Water pump flow：15t/h
  • Working height：750±10mm
  • Air source：0.7Mpa
  • Power：3P 380V/1P+N 220V 50Hz 30kW
  • Machine size：17500(L)×2040(W)×4080(H)mm
VIDEO OF AUTOMATIC ARGON GAS FILLING IG LINE
