Product Introduction

Feature

  • PLC control system and touch screen interface
  • Adjustable filling height according to the spacer size
  • Automatically sealing the drilled hole
  • Automatically monitor the desiccant filling quantity

Technical Data

  • Desiccant diameter：0.5-0.8mm
  • Filling speed：5sec/1000×1000×9mm(double sides)
  • Spacer width：6-24mm
  • Max filling frame size：2000×2000mm
  • Min filling frame size：250×250mm
  • Power：1P+N 220V 50Hz 1kW
  • Air pressure：0.7MPa
  • Machine size：1165(L) × 860(W) × 3050(H)mm
VIDEO OF AUTOMATIC ARGON GAS FILLING IG LINE
